TYPE
|
DESCRIPTION
|
|
|---|---|---|
|
Category
|
Sensors, Transducers
Pressure Sensors, Transducers
|
|
|
Mfr
|
Freescale Semiconductor
|
|
|
Series
|
MPXAZ6115A
|
|
|
Package
|
Bulk
|
|
|
Product Status
|
Active
|
|
|
Applications
|
Board Mount
|
|
|
Pressure Type
|
Absolute
|
|
|
Operating Pressure
|
2.18PSI ~ 16.68PSI (15kPa ~ 115kPa)
|
|
|
Output Type
|
Analog Voltage
|
|
|
Output
|
0.2 V ~ 4.7 V
|
|
|
Accuracy
|
±1.5%
|
|
|
Voltage – Supply
|
4.75V ~ 5.25V
|
|
|
Port Size
|
Male – 0.13″ (3.17mm) Tube
|
|
|
Port Style
|
Barbed
|
|
|
Features
|
Temperature Compensated
|
|
|
Termination Style
|
Gull Wing
|
|
|
Maximum Pressure
|
58.02PSI (400kPa)
|
|
|
Operating Temperature
|
-40°C ~ 125°C
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Package / Case
|
8-SMD, Gull Wing, Side Port
|
|
|
Supplier Device Package
|
8-SOP
|
MPXAZ6115AP
|
Part Number
|
2156-MPXAZ6115AP-ND
|
|
|
Manufacturer
|
Freescale Semiconductor
|
|
|
Manufacturer Product Number
|
MPXAZ6115AP
|
|
|
Description
|
SENSOR 16.68PSIA 0.13″ 4.7V 8SOP
|
|
|
Detailed Description
|
Pressure Sensor 2.18PSI ~ 16.68PSI (15kPa ~ 115kPa) Absolute Male – 0.13″ (3.17mm) Tube 0.2 V ~ 4.7 V 8-SMD, Gull Wing, Side Port
|
Enquiry about MPXAZ6115AP
Description
Datasheet
Datasheet
Environmental & Export Classifications
Environmental & Export Classifications
| ATTRIBUTE | DESCRIPTION |
|---|---|
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
Additional Resources
Additional Resources
| ATTRIBUTE | DESCRIPTION |
|---|---|
| Other Names |
FREFREMPXAZ6115AP
2156-MPXAZ6115AP
|
| Standard Package | 1 |
