2.3 Inch 5X8 Square Dot Matrix LED Display with RoHS
1. Summary:
| Digit Height: | 2.3 inch digit height |
| Available Emitting color: | Red, yellow-green, orange, amber, yellow, pure green, blue, white |
| Available Face color: | Red, white, grey, and black. |
| Available Segment Color: | Red, white (milky),water clear, and yellow. |
| Available Electrode: | Common anode or common cathode |
2. What emitting color you can have?
| Part No. | Chip | IV@IF=20mA | Iv@IF=20mA | |||||
| Common Cathode | Common Anode |
Material | Color | WLD | One Seg | One DP | ||
| Min. | Typ. | Min. | Typ. | |||||
| LM23158AUR | LM23158BUR | AlGaInP | Ultra Red | 633 | 30 | 45 | 30 | 45 |
| LM23158AUO | LM23158BUO | AlGaInP | Ultra Orange | 625 | 45 | 60 | 45 | 60 |
| LM23158AUA | LM23158BUA | AlGaInP | Ultra Amber | 605 | 30 | 45 | 30 | 45 |
| LM23158AUY | LM23158BUY | AlGaInP | Ultra Yellow | 595 | 30 | 45 | 30 | 45 |
| LM23158AUG | LM23158BUG | AlGaInP | Ultra Green | 573 | 30 | 45 | 30 | 45 |
| LM23158APG | LM23158BPG | InGaN | Pure Green | 525 | 120 | 300 | 120 | 300 |
| LM23158AUB | LM23158BUB | InGaN | Ultra Blue | 470 | 30 | 45 | 30 | 45 |
| LM23158AW | LM23158BW | InGaN | Ultra White | 100 | 120 | 100 | 120 | |
| Unit: | nm | mcd | mcd | mcd | mcd | |||
3. What max voltage and current you can use to drive it?
| Color | Electrical Characteristics[1] | Absolute Maximum Ratings[1] | |||||
| VF@ IF=20mA[2] | Reverse Current VR=5V |
Power Dissipation | DC Forward Current | Peak Forward Current[3] | |||
| Typ. | Max. | ||||||
| Ultra Red | 1.9 | 2.6 | 30 | 60 | 20 | 100 | |
| Ultra Orange | 2.0 | 2.6 | 30 | 65 | 20 | 100 | |
| Ultra Amber | 2.0 | 2.6 | 30 | 65 | 20 | 100 | |
| Ultra Yellow | 2.0 | 2.6 | 30 | 65 | 20 | 100 | |
| Yellow green | 2.1 | 2.6 | 30 | 75 | 20 | 100 | |
| Pure Green | 3.0 | 3.6 | 30 | 110 | 20 | 100 | |
| Blue | 3.0 | 3.6 | 30 | 120 | 20 | 100 | |
| White | 3.0 | 3.6 | 30 | 120 | 20 | 100 | |
| Unit: | V | V | uA | mW | mA | mA | |
>>>MICRO IC LED Dot Matrix Series
Ø The common types: 4X4, 5X7, 5X8, 8X8, and 16X16.
Ø The common size: 0.7 inch,1 inch,1.2 inch,1.5inch,2 inch,3 inch, and 4 inch.
Ø Through-hole type or SMD Type is available.
Ø Round dot or Square dot is available.
Ø Our White color LED dot matrix is high-quality made with Good brightness Uniformity compared to common white color products in the market.
Ø Customized is available. Design according to your demand.
